SP2-L2-DC12V
| 制造商 | |
| 描述 | General Purpose Relays 15A 12VDC DPDT 2 COIL LATCH PLUG-IN Electromechanical Relay DPDT 10ADC/15AAC 12VDC 480Ohm Plug-In RELAY GEN PURPOSE DPDT 15A 12V POWER RELAY, DPDT, 12VDC, 15A, PLUG IN Power Relay Coil Voltage: 12 VDC Contact Configuration: 2C DPDT Current: 15 Amps Mounting: Plug-in Operating Function: 2 Coil Latching SP Series 15 A DPDT 12 VDC Socket Mount Polarized 2 Coil Latching Power Relay |
| 分类 |
对参数有疑问？问 AI 助手
商业参数
| 产品类别 | General Purpose Relays | 标准包装数量 | 20 |
| 工厂包装数量 | 20 | ||
合规参数
| RoHS | RoHS Compliant By Exemption | 欧盟RoHS | Compliant |
| 海关税号 | 85364110 | ||
电气参数
| 线圈类型 | Dual Coil Latching | 线圈功率 | 300 mW |
| 量程（°/s） | :PANASONIC EW - SP Series | 线圈电流 | 25 mA |
| 释放时间 | 30ms | 额定功率 | 300W|3.75kVA |
| 可见输出 | No | 额定电压 | 30 |
| 线圈电阻 | 480 Ohms | 推频（MHz/V） | No |
| 输出电流 | :15A | 供电电压 | 12 V |
| 开关电压 | 250VAC, 30VDC - Max | 钳位电压 | 8.4VDC |
| 二极管配置 | No | 最大额定电流 | 10DC|15AC |
| 触点电压（最大） | :250V | 最小输入电压 | 250 |
| 平均正向功率 | 300 mW | 集电极-发射极饱和电压（最大）@ Vge, Ic | 8.4 VDC |
| 触点额定电流 | 15A | 数字供电电压 | :30V |
机械参数
| 密封 | Unsealed | 深度 | 25.6 |
| 高度 | 27.65 | 重量 | 0.05 |
| 包装方式 | Bulk | 触点形式 | 2 Form C (DPDT-BM) |
| 安装类型 | Plug-In | 安装样式 | Plug In |
| 冷却的封装 | Dust Cover | 触头材料 | Silver Tin Oxide |
| 总长度 | 51 | 端接样式 | Quick Connect |
| 触点数 | 10 | 接触件端接 | Quick Connect |
| 典型触点布局 | DPDT | ||
产品信息
| 类型 | Power Relay | 系列 | :SP |
| 继电器类型 | Latching Double Coil | ||
环境参数
| 动作时间 | 30ms | 工作温度 | -50°C ~ 60°C |
