点击放大查看
AXT440124
| 制造商 | |
| 描述 | Conn Board to Board HDR 40 POS 0.4mm Solder ST SMD Embossed T/R CONN HEADER FPC .4MM 40POS SMD FFC & FPC Connectors CONN HEADER FPC 40 POS 0.4mm |
| 分类 |
对参数有疑问？问 AI 助手
商业参数
| 其他名称 | 255-3312-1 | 标准包装数量 | 1,000 |
| 工厂包装数量 | 3000 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
电气参数
| 额定电压 | 60 V | 接触电阻 | 90 mohm |
| 最大额定电流 | 300 mA | 最小输入电压 | 60VDC|60VAC |
| 最小供电电压 | 60VDC/60VAC | ||
机械参数
| 深度 | 2.35 mm | 间距 | 0.4 mm |
| 高度 | 1.24 mm | 包装方式 | Embossed Tape and Reel |
| 端接方式 | Solder | 安装类型 | Surface Mount |
| 连接器类型 | Header, Center Strip Contacts | 接触镀层 | Gold Over Nickel |
| 安装样式 | Surface Mount | 排数 | 2 |
| 触头材料 | Copper Alloy | 壳体材料 | Liquid Crystal Polymer |
| 总长度 | 9.9 mm | 端接样式 | SMD |
| 板面高度 | 0.049" (1.25mm) | 触点数 | 40 |
| 位数 | 40 | 配接堆叠高度 | 1.5mm, 2.5mm |
产品信息
| 类型 | Board to Board | 连接器性别 | HDR |
| 系列 | P4S | 产品特性 | Solder Retention |
| 产品子类型 | Headers | ||
环境参数
| 工作温度 | -55C to 85C | ||
文档与媒体
PDF 文档
PDF 文档
PDF 文档
