XS2M-D424-2
| 制造商 | |
| 描述 | Circular Metric Connectors CONNECTOR CONNECTOR PLUG DC SOLDER CUP Conn Circular PIN 4 POS Solder Cup ST Panel Mount 4 Terminal 1 Port 欧姆龙(OMRON) 其它传感器附件 Circular Connector Connector Type: Plug, Male Pins Number of Positions: 4 Shell Size - Insert: M12-4 Mounting Type: Panel Mount, Bulkhead - Front Side Nut Fastening Type: Threaded |
| 分类 |
商业参数
| 交货时间 | 96 Days | 子类别 | Connector Circular |
| 零件号别名 | 385577 | 产品类别 | Circular Metric Connectors |
| 标准包装数量 | 50 | 工厂包装数量 | 50 |
合规参数
| RoHS | Lead free / RoHS Compliant | ||
电气参数
| 额定电压 | 250VAC, 125VDC | 最大额定电流 | 3A |
机械参数
| 包装方式 | Bulk | 方向 | Keyed |
| 端接方式 | Solder Cup | 安装类型 | Panel Mount, Bulkhead - Front Side Nut |
| 连接器类型 | Plug, Male Pins | 接触镀层 | Gold |
| 紧固类型 | Threaded | 位数 | 4 |
| 外壳尺寸-插件 | M12-4 | 外壳材料及表面处理 | Brass, Nickel Plated |
| 接触镀层厚度 | 16µin (0.40µm) | ||
产品信息
| 类型 | Connectors & Jacks | 系列 | M12 |
| 卡标准 | Circular Connector | ||
环境参数
| 防护等级 | IP67 - Dust Tight, Waterproof | 工作温度 | -25°C ~ 70°C |
