71661-7050
| 制造商 | Molex, LLC |
| 描述 | CONN PLUG VERTICAL 50POS .050 Board to Board & Mezzanine Connectors 1.27MM VERT 50P PLG BLIND MATE Conn EBBI PL 50 POS 2.54mm Solder ST Thru-Hole 50Terminal 1Port Tray Conn EBBI PL 50 POS 2.54mm Solder ST Thru-Hole 50 Terminal 1 Port Tray |
| 分类 |
商业参数
| 商标名 | EBBI 50D | 零件号别名 | 0716617050 |
| 产品类别 | Board to Board & Mezzanine Connectors | 标准包装数量 | 1 |
| 工厂包装数量 | 784 | ||
合规参数
| RoHS | RoHS Compliant | ||
电气参数
| 额定电压 | 30 V | 最大额定电流 | 1 A |
机械参数
| 间距 | 0.050" (1.27mm) | 包装方式 | Tray |
| 安装类型 | Through Hole | 连接器类型 | Plug, Center Strip Contacts |
| 接触镀层 | Gold | 排数 | 2 |
| 触头材料 | Copper Alloy | 壳体材料 | Thermoplastic |
| 端接样式 | Through Hole | 板面高度 | 0.362" (9.20mm) |
| 触点数 | 50 | 位数 | 50 |
| 接触镀层厚度 | 30µin (0.76µm) | ||
产品信息
| 系列 | 71661 | 产品特性 | Board Guide |
| 产品子类型 | Plugs | ||
文档与媒体
相关型号
76650-0173
