点击放大查看
123-13-320-41-001000
| 制造商 | Mill-Max Mfg. Corp. |
| 描述 | Conn DIP Socket SKT 20 POS 2.54mm Wire Wrap ST Thru-Hole Tube W/W IC SOCKET 20 PIN .300 GOLD Socket; DIP;Open;4-Finger;20 Pos.;0.3In.;30muIn. Gold;0.510In.;50V;3A;-25 to 85d IC & Component Sockets 20P GLD PIN GLD CONT DIP SOCKET, 20POS, THROUGH HOLE Socket,DIP;Open;4-Finger;20Pos.;0.3In.;30muIn.Gold;0.510In.;50V;3A;-25to85d |
| 分类 |
商业参数
| 产品 | DIP / SIP Sockets | 交货时间 | 20 Days |
| 子类别 | Connector Socket | 产品类别 | IC & Component Sockets |
| 标准包装数量 | 20 | 工厂包装数量 | 20 |
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
| 海关税号 | 85369010 | ||
电气参数
| 接触电阻 | 10 | 最大额定电流 | 3 |
| 绝缘电阻 | 10000 | 最小输入电压 | 150VDC |
机械参数
| 深度 | 10.16 | 间距 | 0.100" (2.54mm) |
| 高度 | 4.9 | 重量 | 0.002 |
| 包装方式 | Tube | 排间距 | 7.62 |
| 端接方式 | Wire Wrap | 柱间距 | :7.62mm |
| 安装类型 | Through Hole | 连接器类型 | :DIP Socket |
| 接触镀层 | Gold Over Nickel | 安装样式 | Through Hole |
| 排数 | 2 | 触头材料 | Beryllium Copper |
| 壳体材料 | Polychlorinated Terphenyl | 总长度 | 25.4 |
| 端接样式 | Solder Pin | 触点数 | 20 |
| 接触件端接 | :Wire Wrap | 绝缘材料 - 类型 | Polychlorinated Terphenyl |
| 接触镀层厚度 | 30µin (0.76µm) | 位置或引脚数（网格） | 20 (2 x 10) |
产品信息
| 类型 | DIP Socket | 连接器性别 | SKT |
| 系列 | :123 | 产品特性 | Open Frame |
| 适用产品/相关产品 | 123-93-320-41-001000123-91-320-41-001000 | ||
