03420038H
| 制造商 | |
| 描述 | Fuse Holders 3AG 3AG FUSEHLDR ACS 3AG FUSEHLDR FUSE HLDR CART 250V 15A PNL MNT FUSE HOLDER, 6.3 X 32MM, PANEL MOUNT |
| 分类 |
商业参数
| 最小起订量 | 1 | 产品 | Fuse Holders |
| 单位包装 | 0 | 产品类别 | Fuse Holders |
| 标准包装数量 | 100 | 工厂包装数量 | 100 |
合规参数
| RoHS | RoHS Compliant | 海关税号 | 85361010 |
电气参数
| 电压 | 250V | 额定电压 | 250 V |
| 极数 | 1 | 额定交流电压 | :250V |
| 最大额定电流 | 20 A | 触点电压（最大） | :250V |
| 每极负载侧连接方式 | :Quick Connect | ||
机械参数
| 颜色 | Black | 重量 | 0.014 |
| 包装方式 | Bulk | 轴细节 | Bayonet Knob Release |
| 安装类型 | Panel Mount | 接触镀层 | Tin |
| 安装样式 | Panel | 保险丝座类型 | Holder |
| 触头材料 | Brass | 端接样式 | Quick Connect - 0.187" (4.7mm) |
产品信息
| 系列 | 342 | 保险丝尺寸 | 1/4" Dia x 1-1/4" L (6.35mm x 31.8mm) |
| 保险丝类型 | Cartridge | 照明类型 | No |
| 电路数 | 1 | 附带电池数量 | :1 |
| 适用产品/相关产品 | 3AG | ||
环境参数
| 工作温度 | - 40 C to + 85 C | ||
文档与媒体
