点击放大查看
商业参数
| 标准包装数量 | Bulk | ||
合规参数
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85369010 | 认证机构 | :MIL-C-26482 |
电气参数
| 额定电压 | 600VAC, 850VDC | 最大额定电流 | 7.5A |
机械参数
| 重量 | 0.001 | 包装方式 | Bulk |
| 方向 | N (Normal) | 端接方式 | Crimp |
| 重量（g） | 65.60000 | 安装类型 | Cable Mount |
| 连接器类型 | Receptacle, Male Pins | 接触镀层 | Gold |
| 紧固类型 | Bayonet Lock | 插入角度 | :16-26 |
| 本体材料 | :Aluminium | 触头材料 | :Copper |
| 第一触头极性 | :Pin | 触点数 | :26 |
| 接触件端接 | :Crimp | 位数 | 26 |
| 外壳尺寸-插件 | 16-26 | 外壳材料及表面处理 | Aluminum, Olive Drab Cadmium Plated |
| 接触镀层厚度 | 50µin (1.27µm) | 第一连接器安装类型 | :Cable |
产品信息
| 类型 | MIL-C-26482 Circular | 连接器性别 | PL |
| 系列 | :KPSE | 产品特性 | Sealing Gland, Strain Relief |
环境参数
| 防护等级 | Environment Resistant | 工作温度 | -55°C ~ 125°C |
文档与媒体
相关型号
KPSE06E16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Crimp ST Cable Mount 26 Terminal 1 Port CONN PLUG 26POS CBL MNT W/SKTS CONNECTOR, CIRC, 16-26, 26WAY, SIZE 16
KPSE06J16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Crimp ST Cable Mount 26 Terminal 1 Port CONN PLUG 26POS CBL MNT W/SKTS CONNECTOR, CIRCULAR, SIZE 16, 26WAY
KPT06E16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Solder ST Cable Mount 26 Terminal 1 Port CONN PLUG 26POS CABLE W/SKT CIRCULAR, SIZE 16, 26 WAY SKT
KPSE06F16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Crimp ST Cable Mount 26 Terminal 1 Port CONN PLUG 26POS CBL MNT W/SKTS CONNECTOR, CIRCULAR, SIZE 16, 26WAY
KPSE08E16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Crimp RA Cable Mount 26 Terminal 1 Port CONN PLUG 26POS CBL MNT W/SKTS
KPSE06P16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Crimp ST Cable Mount 26 Terminal 1 Port CONN PLUG 26POS CABLE SKT
KPT08P16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Solder RA Cable Mount 26 Terminal 1 Port CONN PLUG 26POS INLINE W/SKTS CIRCULAR, SIZE 16, 26 WAY SKT
KPSE08P16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Crimp RA Cable Mount 26 Terminal 1 Port CONN PLUG 26POS INLINE W/SKTS CIRCULAR, SIZE 16, 26 WAY PIN
KPT08F16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Solder RA Cable Mount 26 Terminal 1 Port CONN PLUG 26POS CABLE RA SKT CIRCULAR, SIZE 16, 26 WAY SKT
KPSE08F16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Crimp RA Cable Mount 26 Terminal 1 Port CONN PLUG 26POS CABLE RA SKT
KPT06J16-26S
itt interconnect solutions
Conn MIL-C-26482 Circular SKT 26 POS Solder ST Cable Mount 26 Terminal 1 Port CONN PLUG 26POS CABLE W/SKT CIRCULAR, SIZE 16, 26 WAY SKT
KPSE06E16-26SDX
ITT Cannon
CONN PLUG 26POS CBL MNT W/SKTS CIRCULAR, SIZE 16, 26 WAY SKT
KPSE06F16-26SF187
ITT Cannon
CONN PLUG 26POS CBL MNT W/SKTS CIRCULAR, SIZE 16, 26 WAY SKT
KPSE6F16-26SDX
ITT Cannon
CONN PLUG 26POS W/SKT CIRCULAR, SIZE 16, 26 WAY SKT
KPSE06F16-26SDX
ITT Cannon
CONN PLUG 26POS W/SKT CABLE CIRCULAR, SIZE 16, 26 WAY SKT
KPT06E16-26SF80
ITT Cannon
CONN PLUG 26POS W/SKT CABLE CIRCULAR, SIZE 16, 26 WAY SKT
KPT6E16-26SDN
ITT Cannon
CONN PLUG 26POS CABLE SKT
KPSE6E16-26SDN
ITT Cannon
CONN PLUG 26POS CBL MNT W/SKTS CIRCULAR, SIZE 16, 26 WAY SKT
KPSE06E16-26SDN
ITT Cannon
CONN PLUG 26POS CBL MNT W/SKTS CIRCULAR, SIZE 16, 26 WAY SKT
KPSE06F16-26SDN
ITT Cannon
CONN PLUG 26POS W/SKT CABLE CIRCULAR, SIZE 16, 26 WAY SKT
