点击放大查看
商业参数
| 其他名称 | KPSE01E2039P | 标准包装数量 | Bulk |
合规参数
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85369010 | 认证机构 | :MIL-C-26482 |
电气参数
| 额定电压 | 600VAC, 850VDC | 最大额定电流 | 7.5A, 13A |
机械参数
| 重量 | 0.001 | 包装方式 | Bulk |
| 方向 | N (Normal) | 端接方式 | Crimp |
| 重量（g） | 52.94200 | 安装类型 | Cable Mount |
| 连接器类型 | Receptacle, Male Pins | 接触镀层 | Gold |
| 紧固类型 | Bayonet Lock | 封装形式 | :Cable Receptacle |
| 插入角度 | :20-39 | 本体材料 | :Aluminium |
| 触头材料 | :Copper | 第一触头极性 | :Pin |
| 触点数 | :39 | 接触件端接 | :Crimp |
| 位数 | 39 | 外壳尺寸-插件 | 20-39 |
| 外壳材料及表面处理 | Aluminum, Olive Drab Cadmium Plated | 接触镀层厚度 | 50µin (1.27µm) |
| 第一连接器安装类型 | :Cable | ||
产品信息
| 类型 | MIL-C-26482 Circular | 连接器性别 | PL |
| 系列 | :KPSE | ||
环境参数
| 防护等级 | Environment Resistant | 工作温度 | -55°C ~ 125°C |
