点击放大查看
商业参数
| 其他名称 | CA3100ER2027P | 标准包装数量 | Bulk |
合规参数
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85369010 | 认证机构 | :MIL-C-5015 |
电气参数
| 额定电压 | 500VAC, 700VDC | ||
机械参数
| 重量 | 0.01 | 包装方式 | Bulk |
| 方向 | N (Normal) | 端接方式 | Solder |
| 重量（g） | 50.22600 | 安装类型 | Wall Mount |
| 连接器类型 | Receptacle, Male Pins | 接触镀层 | Silver |
| 紧固类型 | Threaded | 插入角度 | :20-27 |
| 本体材料 | :Aluminium | 触头材料 | :Copper |
| 第一触头极性 | :Pin | 触点数 | :14 |
| 接触件端接 | :Crimp | 位数 | 14 |
| 外壳尺寸-插件 | 20-27 | 外壳材料及表面处理 | Aluminum, Olive Drab Cadmium Plated |
| 第一连接器安装类型 | :Wall | ||
产品信息
| 类型 | MIL-C-5015 Circular | 连接器性别 | RCP |
| 系列 | :CA-Threaded | ||
环境参数
| 防护等级 | Environment Resistant | 工作温度 | -55°C ~ 125°C |
文档与媒体
