3180-3SG-530

制造商	Switchcraft, Inc.
描述	Standard Circular Connector MULTI-CON CABLE #12 CRIMP Conn Field Installable SKT 3 POS Crimp ST Cable Mount 3 Terminal 1 Port Standard Circular Connectors MULTI-CON CABLE #12 CRIMP CONN PLUG 3POS CABLE SKT MULTI-CONCABLE#12CRIMP
分类	连接器解决方案圆形连接器标准圆形连接器

对参数有疑问？问 AI 助手

商业参数

商标名	Multi-Con-X	标准包装数量	25
工厂包装数量	25

合规参数

RoHS	Lead free / RoHS Compliant	欧盟RoHS	Supplier Unconfirmed
抗辐射加固	No

电气参数

额定电压

600V

最大额定电流

1.95 A to 23 A

机械参数

直径	22.2 mm	包装方式	Bulk
出线方向	No	方向	Keyed
外壳样式	Plug	端接方式	Crimp
触点形式	3Signal	触头类型	3Signal
安装类型	Cable Mount	连接器类型	Plug, Female Sockets
接触镀层	Gold Over Nickel	紧固类型	Bayonet Lock
安装样式	Free Hanging	外壳材料（壳体）	Plastic
触头材料	Brass	总长度	42.8 mm
端接样式	Crimp	第一触头极性	SKT
配接方向	Bayonet	触点数	3
位数	3	外壳材料及表面处理	Nylon

产品信息

类型	Field Installable	系列	Multi-Con-X
产品特性	Cable Clamp	主要用途	Cable Clamp
产品子类型	Connectors	射频系列/标准	31
输出配置	Free Hanging (In-Line)

环境参数

防护等级

Weathertight

工作温度

-40°C ~ 115°C
