LTC4266CIUHF#PBF

制造商	Analog Devices, Inc.
描述	POE Controller 13W 38-Pin QFN EP IC POE 802.3AF QUAD PSE 38-QFN POE, CNTRL, QUAD, 13W, 1MHZ, 38QFN
分类	集成电路电源管理IC通用电源管理IC

对参数有疑问？问 AI 助手

商业参数

其他名称	LTC4266CIUHFPBF	标准包装数量	52
标准封装名称	QFN

合规参数

RoHS	Lead free / RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
欧盟RoHS	Compliant	标准	IEEE802.3at
海关税号	85423990

电气参数

频率	:1MHz	占空比	:6.3%
最大功率	13W	额定电压	:3.3V
输出电流	2.4mA	供电电压	45 V ~ 57 V
通道数量	4	释放电压	:2.2V

机械参数

重量	0.000144	包装方式	Tube
引脚样式	No Lead	引脚数	:38
封装形式	38-WFQFN Exposed Pad	材料表面处理	:MSL 1 - Unlimited
包装数量	QFN EP	位数	38
供应商器件封装	38-QFN (5x7)

产品信息

类型	Controller (PSE)	辅助检测	No
内部开关	No	DigiKey可编程	Yes

环境参数

工作温度

0°C ~ 70°C
