901-9209-ASF
| 制造商 | |
| 描述 | Conn SMA Adapter RCP/RCP 0Hz to 18GHz 50Ohm ST Panel Mount Gold Over Nickel CONN SMA ADAPTER JACK TO JACK connector;rf coaxial;sma in-series adapter;bulkhead jack to jack;passivated RF Adapters - In Series BULDHEAD JCK TO JCK ADAPTER PASSIVATED connector, rf coaxial, sma in-series adapter, bulkhead jack to jack, passivated |
| 分类 |
对参数有疑问？问 AI 助手
商业参数
| 零件号别名 | 713-4246 901-9209-ASF 93F1323 | 产品类别 | RF Adapters - In Series |
| 标准包装数量 | Bulk | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
| 抗辐射加固 | No | ||
电气参数
| 频率 | 0 to 18 GHz | 阻抗 | 50 Ohm |
| 转换速率 | Same Series | 最大频率 | 12.4 GHz |
机械参数
| 高度 | 9.5 mm | 直径 | 9.5 mm |
| 包装方式 | Bulk | 方向 | Straight |
| 重量（g） | 4.80000 | 基体材料 | Stainless Steel |
| 安装类型 | Panel Mount | 外壳镀层 | Passivated |
| 行程角度 | Straight | 接触镀层 | Gold Over Nickel |
| 外壳涂层 | Passivated | 安装样式 | Bulkhead |
| 连接器用途 | Threaded | 触头材料 | Beryllium Copper |
| 壳体材料 | Stainless Steel | 总长度 | 22.2 mm |
| 主要材料 | Adapter | 尺寸/外形 | 0.875 in. L x 0.312 in. Dia. (Hex) |
| 介电材料 | TFE | 绝缘材料 - 类型 | Tetrafluoroethylene Fluorocarbon |
| 第一连接器极性 | Jack | 第二连接器性别 | Jack |
| 中心触点镀层工艺 | Gold | 供应商器件封装 | Straight |
产品信息
| 类型 | SMA Adapter | 样式 | Straight |
| 连接器性别 | RCP/RCP | 适配器类型 | Jack to Jack |
| 中心极性 | Female to Female | 适配器系列 | SMA to SMA |
| 射频系列/标准 | SMA | 应用细节 | Commercial |
| 转换端（适配器端） | SMA Jack, Female Socket | 转换自（适配器端） | SMA Jack, Female Socket |
环境参数
| 工作温度 | -65C to 165C | ||
