| Type | Description |
|---|---|
| Depth | 75mm |
| Dimensions | 100 x 45 x 75mm |
| Efficiency | 88% |
| Input Voltage | 85 → 264 V ac, 85 → 375 V dc |
| Length | 100mm |
| Line Regulation | ±0.2% |
| Load Regulation | ±1% |
| Maximum Temperature | +70°C |
| Minimum Temperature | -10°C |
| MTBF | 2940000h |
| Output Current | 4A |
| Output Voltage | 12V dc |
| Power Rating | 60W |
| Ripple And Noise | 50mV Pk-Pk |
| Type | Switch Mode |
| Weight | 265g |
| Width | 45mm |
| Power Supply Output Type | :Adjustable, Fixed |
| Input Voltage VAC | :85V to 264V |
| No. of Outputs | :1 |
| Output Voltage Nom. | :12V |
| Output Current Max | :4A |
| Output Power Max | :60W |
| Approvals / Standards | :- |
| Approval Bodies | :CB, cUL, EN, IEC, UL |
| Weight (kg) | 0.18 |
| Tariff No. | 85044082 |
