Panasonic
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| Detection Range | 0.1 → 5 m |
| Detection Type | Retroreflective |
| Electrical Connection | Cable |
| Housing Material | PC |
| IP Rating | IP66 |
| Light Source | LED |
| Maximum AC Voltage | 250V |
| Maximum DC Voltage | 30V |
| Maximum Operating Temperature | +55°C |
| Minimum Operating Temperature | -20°C |
| Output Type | Relay |
| Response Time | |
| Sensor Style | Block |
| Dimensions L x W x H | 35 x 18 x 62 mm |
| Sensor type | Reflection light sensor |
| Light type | red, 660 nm |
| Length | 35 |
| Height | 62 |
| Width | 18 |
| Connection | Cable 2 m |
| Operating temperature | -20...+55 °C |
| Operating voltage | 12...240 VDC |
| Response time | 10 ms |
| Output | Relay, 1 changeover contact |
| Switching type | Dark ON |
| Type | Front type |
| Protection rating | IP 66 |
| Switching interval | 0.1...5 m |
| 检测类型 | 后向反射 |
| 最大交流电压 | 250V |
| 最高工作温度 | +55°C |
| 光源 | LED |
| 最低工作温度 | -20°C |
| 传感器样式 | 块状 |
| 外壳材料 | PC |
| 检测范围 | 0.1 → 5 m |
| IP 防护等级 | IP66 |
| 最大直流电压 | 30V |
| 电气连接 | 电缆 |
| 输出类型 | 继电器 |
