panasonic
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| Case Size | 2512 |
| Type | Thick Film |
| Resistance Value | 5 mOhm |
| Tolerance | 1 % |
| Power Rating | 1 W |
| Case Style | Molded |
| Operating Temperature | -55 to 170 °C |
| Temperature Coefficient | ±100 ppm/°C |
| Lead Finish | Tin |
| Standard Package | Tape & Reel |
| Temp.coeff. | 100ppm |
| Matchcode | TR25120,005R1% |
| IEC-Series | E24 |
| Package | 2512 |
| Unit Pack | 3000 |
| Standard Leadtime | 15 weeks |
| MOQ | 3000 |
| Packaging | REEL |
| Res.tolerance | 1% |
| Max.oper.temp. | 170°C |
| Automotive | NO |
| Resistor value | 0.005R |
| Power rating | 1W |
| Min.oper.temp. | -55°C |
| Leadfree Defin. | RoHS-conform |
| Depth | 3.2mm |
| Dimensions | 6.4 x 3.2 x 0.8mm |
| Height | 0.8mm |
| Length | 6.4mm |
| Maximum Operating Temperature | +170°C |
| Maximum Temperature Coefficient | +100ppm/°C |
| Minimum Operating Temperature | -55°C |
| Minimum Temperature Coefficient | -100ppm/°C |
| Package/Case | 2512 |
| Resistance | 5mΩ |
| Technology | Thick Film |
| rohs | Compliant |
| Product Range | :PANASONIC - ERJ Series |
| Resistance Tolerance | :± 1% |
| Resistor Case Style | :2512 [6432 Metric] |
| Resistor Element Material | :Metal Strip |
| MSL | :- |
| No. of Pins | :2 |
| Operating Temperature Max | :170°C |
| Operating Temperature Min | :-55°C |
| Operating Temperature Range | :-55°C to +170°C |
| Resistor Mounting | :SMD |
| Series | :ERJM1W |
| Weight (kg) | 0.07 |
| Tariff No. | 85332100 |
| Material,Element | ThickFilm |
| PackageType | 2512(6432mm) |
| Power,Rating | 1W |
| TemperatureCoefficient | ±100ppm/°C |
| Temperature,Operating,Maximum | 170°C |
| Temperature,Operating,Minimum | –55°C |
| Termination | SMT |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
