点击放大查看
951226-8622-AR
| 制造商 | |
| 描述 | Conn Unshrouded Header HDR 26 POS 2mm Solder ST Thru-Hole 2 mm and 2 mm x 2 mm Straight and Right Angle, Solder Tail CONN HEADER 26POS 2MM VERT T/H Headers & Wire Housings 26P PIN STRP HDR 2R STRT PTH 10U AU |
| 分类 |
商业参数
| 零件号别名 | 04671911447 DE500000521 | 产品类别 | Headers & Wire Housings |
| 标准包装数量 | Bulk | ||
合规参数
| RoHS | Lead free / RoHS Compliant | ||
电气参数
| 最大额定电流 | 1 A | ||
机械参数
| 颜色 | Black | 间距 | 2 mm |
| 包装方式 | Bulk | 排间距 | 0.079" (2.00mm) |
| 端接方式 | Solder | 触头类型 | Male Pin |
| 安装类型 | Through Hole | 连接器类型 | Header, Unshrouded |
| 接触镀层 | Gold Over Nickel | 排数 | 2 |
| 触头材料 | Copper Alloy | 壳体材料 | Thermoplastic |
| 端接样式 | Through Hole | 第一触头极性 | Pin (Male) |
| 触点数 | 26 | 位数 | 26 |
| 接触长度 - 配合 | 0.173" (4.40mm) | 接触镀层厚度 | Flash |
产品信息
| 类型 | Unshrouded Header | 连接器性别 | HDR |
| 系列 | 951 | 产品子类型 | Headers |
| 加载位置数 | All | ||
环境参数
| 工作温度 | - 40 C to + 105 C | ||
