SCHNEIDER ELECTRIC / TELEMECANIQUE
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 工作电压 | :48VDC |
| Switching Power AC3 | :4kW |
| Switching Current AC3 | :9A |
| No. of Poles | :3 |
| 联系配置 | :3NO / 1NO |
| Contactor Direction | :- |
| Relay Mounting | :DIN Rail |
| Coil Voltage VDC Nom | :24V |
| SVHC | :No SVHC (20-Jun-2013) |
| Aux Contact Current Max | :6A |
| Aux Contact Voltage AC Max | :660V |
| Coil Holding Power | :4.5VA |
| Coil Operating Lower Percent Limit | :70% |
| Coil Operating Upper Percent Limit | :130% |
| Coil Pull-in Power | :30VA |
| 线圈类型 | :DC |
| Contact Current DC Max | :9A |
| Contact Current Max | :20A |
| Contact Voltage AC Max | :690V |
| Contact Voltage DC Max | :24V |
| DC Coil Power | :1.5W |
| 外部深度 | :57mm |
| External Length / Height | :58mm |
| 外宽 | :45mm |
| Main Contact Current AC1 Max | :20A |
| Main Contact Current AC3 Max | :9A |
| 安装类型 | :DIN Rail |
| Operating Temperature Max | :50°C |
| Operating Temperature Min | :-25°C |
| 继电器类型 | :Contactor |
| 系列 | :LP |
| Switch Current Max | :110A |
| Switching AC3 Power Max | :4kW |
| Switching Current Max | :110A |
| 端接类型 | :Screw |
| Weight (kg) | 0.22 |
| Tariff No. | 85364900 |
| Switching capacity | 4kW |
| Operating current max | 9A |
| Contactor type | 3-pole |
| 安装 | DIN |
| Control voltage | 24V DC |
| Integrated auxiliary contacts | NO |
| Contactor series | LP4K |
| Gross weight | 0.22 kg |
| Multiplicity | 1 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
