Schneider Electric
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 生物识别技术 | Biometric |
| 直径 | 22 mm |
| 形式 | Rectangular |
| IP等级 | IP65 |
| 最大电流 | 200 mA |
| 最大直流电压 | 24V |
| 按钮触动 | Maintained |
| 按键材料 | PA 66 |
| 终端类型 | Cable |
| 控制类型 | Biometric Switch |
| 额定电流 | 200 mA |
| 额定电压 | 24 V |
| 系列 | Harmony XB5S |
| 安装风格 | Cable |
| 适用于 | :Machine or Systems |
| Approvals / Standards | :IEC 60529 |
| IP / NEMA Rating | :IP65 |
| SVHC | :Benzyl butyl phthalate (BBP) (20-Jun-2013) |
| 执行器类型 | :Bistable |
| Approval Bodies | :CE, IEC, SCA |
| Approval Category | :UL Recognised |
| Behind Panel Depth | :39.7mm |
| 颜色 | :Dark gray |
| 外部深度 | :38.8mm |
| External Length / Height | :42.3mm |
| 外宽 | :69.3mm |
| Height Max | :54mm |
| Operating Temperature Max | :50°C |
| Operating Temperature Min | :-5°C |
| 面板开孔直径 | :22mm |
| Shock Resistance | :50 gn, duration 11 ms |
| Supply Voltage Max | :30V |
| Supply Voltage Min | :20V |
| 端接类型 | :Wire Leaded |
| 工作电压 | :24VDC |
| Weight (kg) | 0.202 |
| Tariff No. | 85363090 |
