IDEC Corporation
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 子类别 | I/O Module |
| 交货期 | 63 Days |
| 长度 | :90mm |
| 外宽 | :36mm |
| 外部深度 | :55mm |
| 附件类型 | :Expansion Module |
| 适用于 | :Works only w/ SmartRelay FL1B CPU unit |
| Signal Input Type | :DC |
| Supply Voltage Max | :24VDC |
| Weight (kg) | 0.154 |
| Tariff No. | 85411000 |
| 应用 | Controlling of Conveyor Systems, Vending Machines and Elevated Platforms; Shop Window and Staircase/Corridor Lighting, Irrigation System for Greenhouse Plants, Outdoor Lighting, Control System for Shutters, Step Switch |
| Brand/Series | SmartRelay |
| Current, Supply | 30 to 140 @ 12 VDC, 20 to 75 @ 24 VDC mA |
| 输入类型 | Digital |
| 安装类型 | DIN Rail |
| 输入数 | 4 Digital |
| 输出数 | 4 |
| 输出类型 | Relay |
| Primary Type | Expansion |
| 特殊功能 | Used for Small Automation Task, Complex Task in Engineering |
| 标准 | UL Listed, CSA Certified |
| 类型 | I/O |
| Voltage, Input | 12 to 24 VDC |
| Voltage, Supply | 10.8 to 28.8 VDC |
| RoHS指令 | RoHS Compliant Part |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
