RUBYCON
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 单位包 | 1000 |
| 最小起订量 | 6000 |
| RoHS指令 | Lead free / RoHS Compliant |
| 产品范围 | :RUBYCON - ML Series |
| 电容 | :220µF |
| 电容公差 | :± 20% |
| 额定电压 | :35V |
| 直径 | :10mm |
| 身高 | :9mm |
| Capacitor Terminals | :Radial Leaded |
| 引线间距 | :5mm |
| Life Time @ Temperature | :5000 hours @ 105°C |
| Operating Temperature Min | :-40°C |
| Operating Temperature Max | :105°C |
| SVHC | :No SVHC (20-Jun-2013) |
| External Length / Height | :9mm |
| No. of Pins | :2 |
| Operating Lifetime | :3000h |
| 工作温度范围 | :-40°C to +105°C |
| Ripple Current AC | :360mA |
| 系列 | :ML |
| 终端类型 | :Wire Ended |
| Tolerance - | :20% |
| Voltage Rating V DC | :35V |
| Weight (kg) | 0.002 |
| Tariff No. | 85322200 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
