Bulgin
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 安装类型 | Free Hanging (In-Line), Right Angle |
| 端接类型 | Screw |
| 连接器类型 | Plug, Male Pins |
| 电流 | 10A |
| 保险丝盒 | Drawer Not Required |
| 电压 | 250V |
| 标准包装 | 100 |
| 连接器类型 | IEC 320-C14 |
| 位置数 | 3 |
| 身体上的取向 | Right Angle |
| 额定电流 | 10A |
| 性别 | Male |
| IEC连接器类型 | C14 |
| 端接方式 | Screw Down |
| 额定电压 | 250 V ac |
| RoHS指令 | Compliant |
| 工厂包装数量 | 100 |
| 产品 | Inlets |
| 产品种类 | AC Power Entry Modules |
| 外壳材料 | Nylon |
| 工作温度范围 | - 40 C to + 70 C |
| 安装风格 | Snap In |
| 开关功能 | Not Switched |
| 可燃性等级 | UL 94 V-0 |
| 触点电镀 | Nickel |
| 过滤 | No |
| 融合 | No |
| RoHS | RoHS Compliant |
| 系列 | :- |
| Connector Mounting | :Cable |
| 接触端子 | :Screw |
| SVHC | :No SVHC (19-Dec-2012) |
| Approval Category | :CSA, IMQ, SEMKO, UL, VDE |
| Cable Diameter Max | :7.6mm |
| 外壳材料 | :Black noryl |
| 外部深度 | :51.7mm |
| External Length / Height | :22.6mm |
| 外宽 | :72.1mm |
| Fuse Current | :10A |
| No. of Outlets | :1 |
| Operating Temperature Max | :70°C |
| Operating Temperature Min | :-40°C |
| Voltage Rating V AC | :250V |
| Weight (kg) | 0.032 |
| Tariff No. | 85369010 |
| Electrical mounting | screw terminal |
| Mechanical mounting | for cable |
| 额定电流 | 10A |
| Multiplicity | 1 |
| Connector variant | C14 (E) |
| Spatial orientation | right |
| Connector type | male |
| 连接器 | plug |
| Gross weight | 0.02 kg |
| Body material | polyamide |
| Operating temperature | -40...70°C |
| 额定电压 | 250V AC |
| Collective package [pcs] | 100 |
| spg | 100 |
