Bulgin
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 产品种类 | Battery Holders, Snaps & Contacts |
| RoHS | RoHS Compliant |
| 产品 | Battery Holders |
| 电池尺寸 | C |
| 电池数量 | 2 |
| 端接类型 | Solder Tabs |
| 材质 | Nylon, Glass Filled |
| 安装风格 | Panel |
| 触点电镀 | Tin |
| 外形尺寸 | 108.7 mm |
| 系列 | BXS |
| 工厂包装数量 | 10 |
| 类型 | Sealed Battery Holder |
| 风格 | Holder (Covered) |
| 安装类型 | Panel Mount |
| 单元数 | 2 |
| 工作温度 | -30°C ~ 70°C |
| 标准包装 | 10 |
| 电池类型，功能 | Cylindrical, Holder |
| RoHS指令 | Lead free / RoHS Compliant |
| 阀体材质 | Glass Filled PET, Nylon |
| 对于电池尺寸 | 2 x C |
| 安装 | Panel |
| 终端触点材料 | Brass |
| 终端触点类型 | Solder Tag |
| Battery Sizes Accepted | :C |
| No. of Batteries | :2 |
| Battery Holder Mount | :Panel |
| Battery Terminals | :Solder Tab |
| 附件类型 | :Battery Holder |
| Battery Size Code | :C |
| 颜色 | :Black |
| 适用于 | :C Batteries |
| No. of Cells | :2 |
| 终端类型 | :Solder Tab |
| 端接方式 | :Tab |
| Weight (kg) | 0.04 |
| Tariff No. | 85369010 |
| Leads | soldering lugs |
| Flammability rating | UL94V-0 |
| Battery size | C, R14 |
| Multiplicity | 1 |
| Body material | polyamide |
| Gross weight | 0.03 kg |
| Operating temperature | -30...70°C |
| Battery accessory type | holder |
| Number of batteries | 2 |
| Collective package [pcs] | 10 |
| 密封 | IP67 (from the front) |
| spg | 10 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
