3M
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 连接器类型 | :Splice |
| 系列 | :SCOTCHLOK |
| Insulator Colour | :Blue |
| 端接方式 | :Crimp |
| 梭哈/标签大小 | :- |
| Wire Size AWG Min | :18AWG |
| Wire Size AWG Max | :16AWG |
| 触点材料 | :Brass |
| 触点电镀 | :Tin |
| 绝缘材料 | :PP (Polypropylene) |
| SVHC | :No SVHC (19-Dec-2012) |
| 颜色 | :Light Blue |
| 额定电流 | :15A |
| Operating Temperature Max | :140°C |
| Operating Temperature Min | :-40°C |
| Voltage Rating V AC | :600V |
| Voltage Rating V DC | :600V |
| Wire Area Size Max | :1.5mm² |
| Wire Area Size Min | :0.75mm² |
| 线径 | :3.68mm |
| 线径规格 | :16AWG |
| Wire Size (AWG) | :18AWG to 16AWG |
| Wire Size Range (AWG) | :18-16 |
| Weight (kg) | 0.155 |
| Tariff No. | 85369010 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
