3m interconnect solutions
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 类型 | DIP Socket |
| 性别 | SKT |
| 触点数 | 14 |
| 间距 | 2.54 mm |
| 端接方式 | Solder |
| 安装 | Through Hole |
| 身体上的取向 | Straight |
| 行数 | 2 |
| 标准包装 | Bulk |
| 欧洲RoHS标准 | Yes |
| 产品特点 | Open Frame |
| 安装类型 | Through Hole |
| 触点表面涂层 | Tin |
| 位置或引脚（网格）的数量 | 14 (2 x 7) |
| Contact Finish Thickness | 35µin (0.90µm) |
| RoHS指令 | Lead free / RoHS Compliant |
| 工厂包装数量 | 100 |
| 产品 | DIP / SIP Sockets |
| 产品种类 | IC & Component Sockets |
| 额定电流 | 1 A |
| 工作温度范围 | - 25 C to + 85 C |
| 额定电压 | 100 VAC |
| 端接类型 | Solder Tail |
| 插座/封装类型 | Open Frame |
| 外壳材料 | Polyester |
| 位置/触点数 | 14 |
| 可燃性等级 | UL 94 V-0 |
| 安装风格 | Through Hole |
| 触点电镀 | Tin over Nickel |
| 零件号别名 | 05111175233 80000913089 |
| 行间距 | 7.62 mm |
| RoHS | RoHS Compliant |
| 触点材料 | Phosphor Bronze |
| 连接器类型 | :DIP Socket |
| 系列 | :4800 |
| No. of Contacts | :14 |
| 节距 | :2.54mm |
| Row Pitch | :7.62mm |
| 接触端子 | :Through Hole Vertical |
| Weight (kg) | 0 |
| Tariff No. | 85366930 |
| Brand/Series | 4800Series |
| Material,Contact | PhosphorBronze |
| NumberofContacts | 14 |
| PinSpacing | 0.1In. |
| PrimaryType | DIP |
| RowSpacing | 0.3In. |
| SpecialFeatures | DualWipe |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
