VISHAY
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 单位包 | 10 |
| 最小起订量 | 50 |
| 主体颜色 | Black |
| 指示灯颜色 | Black |
| 旋钮直径 | 17.65mm |
| 旋钮高度 | 11.94mm |
| 轴尺寸 | 6.35 Dia.mm |
| RoHS指令 | Compliant |
| 轴直径 | :6.35mm |
| No. of Turns | :10 |
| Dial Composition | :Satin Transparent Anodize |
| 附件类型 | :Counting Dial |
| 应用范围 | :10 Turns Precision Potentiometers or Other Rotating Devices |
| 阀体材质 | :Plastic |
| 外部深度 | :22mm |
| External Length / Height | :44.5mm |
| 外宽 | :25.4mm |
| 安装孔直径 | :3.25mm |
| 适用于 | :10 Turn Digital Potentiometers |
| 材质 | :Satin Chrome |
| Operating Temperature Max | :50°C |
| Operating Temperature Min | :-20°C |
| 面板开孔直径 | :19.05mm |
| 系列 | :15 |
| Weight (kg) | 0.04235 |
| Tariff No. | 85339000 |
| 轴直径 | 6.35mm |
| Knob dimensions | 44.5 x 25.4 x 22mm |
| Kind of screen | transparent |
| Shaft surface | smooth |
| 应用 | for multiturn potentiometers |
| Number of mechanical turns | 10 |
| Knobs features | with brake function |
| Kind of knob | with counting dial |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
