Mean Well
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 产品种类 | LED Drivers Power Supplies |
| RoHS | RoHS Compliant |
| 操作模式 | Constant Current (CC) |
| 额定输出功率 | 60 W |
| 输入电压 | 90 VAC to 264 VAC, 127 VDC to 370 VDC |
| 输出数 | 1 |
| 输出电压（通道1 ） | 12 VDC |
| 输出电流（通道1 ） | 5 A |
| 安装风格 | Chassis |
| 外形尺寸 | 181.5 mm L x 62 mm W x 35 mm H |
| 商用/医用 | Commercial |
| 产品 | Switching Supplies |
| 输出电压通道1 | 12 VDC |
| 系列 | PLC-60 |
| 输出电流通道1 | 5 A |
| Bulit-In Dimming Control | |
| Secondary Circuit Required (Hi-Ripple) | Required |
| 功率 | 60 W |
| Output(s) | 12.0V @ 5.00A |
| IP Rated | |
| 输出电压 | 12~48 |
| Package and Dimensions | PLASTIC7.14 x 2.44 x 1.38" |
| Adjust Type | Voltage & Current |
| PFC | PFC |
| Temp Range | -30~+50C |
| 效率 | 85.00% |
| Constant Current or Constant Voltage | CV + CC |
| In Stock | 10 |
| 输入 | 90-264VAC |
| Eff | 85-89% |
| 重量 | 410 |
| 功率 | 60 |
| 输出电流 | 5 |
| 宽度 | 62 |
| Dimensions W x D x H | 62 x 181.5 x 35 mm |
| Operating temperature | -30...50 °C |
| 身高 | 35 |
| Input frequency | 47...63 Hz |
| 深度 | 181.5 |
| 输出电压 | 12 VDC |
| Termination type | Screw Terminal |
| Supply voltage, AC | 90...264 VAC |
| Supply voltage, DC | 127...370 VDC |
