Mean Well
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 输出数 | 1 |
| 产品 | Switching Supplies |
| 产品种类 | Linear and Switching Power Supplies |
| 外形尺寸 | 218 mm L x 105 mm W |
| 商用/医用 | Commercial |
| 额定输出功率 | 297 W |
| 输出电压通道1 | 3.3 VDC |
| 身高 | 41 mm |
| 安装风格 | Chassis |
| 宽度 | 105 mm |
| 长度 | 218 mm |
| 输入电压 | 85 VAC to 264 VAC, 120 VDC to 370 VDC |
| 单位重量 | 2.624 lbs |
| 开放式/封闭式 | Enclosed |
| 输出电流通道1 | 90 A |
| Max Power | 450 Watts |
| Output(s) | 3.3V @ 90.00A |
| 系列 | MEAN WELLHRP-450 |
| Vout Range | 3.3 ~ 48 VDC |
| 效率 | 80.00% |
| Dimensions (Inches) | 8.56 x 4.13 x 1.61" |
| # of Outputs | 1 Output |
| In Stock | 3 |
| Dimensions L x W x H | 218 x 105 x 41 mm |
| Output voltage 1 | 3.3 VDC |
| DC input voltage | 120...370 VDC |
| 功率 | 297 |
| Input frequency | 47...63 Hz |
| Output current 1 | 90 A |
| AC input voltage | 85...264 VAC |
| Operating temperature | -40...+70 °C |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
