AMPROBE
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 功能 | Voltage, Current, Resistance |
| 风格 | Handheld |
| 产品特点 | Hold, Min/Max, Voltage Detector |
| 显示计数 | 2000 |
| 显示位数 | 3.5 |
| 显示器类型 | LCD |
| 响应 | Average |
| 功能，附加 | Battery Test, Continuity, Diode Test |
| 测距 | Manual |
| 标准包装 | 1 |
| 包括 | Battery, Manual, Test Leads, Hanger |
| 类型 | Digital (DMM) |
| 其他名称 | 2727851 |
| 产品 | Multimeters |
| 产品种类 | Digital Multimeters |
| 数字位数 | 3 1/2 Digit LCD |
| 电阻范围 | 200 Ohms to 20 MOhms |
| 真有效值 | No |
| 单位重量 | 7.407532 oz |
| RoHS | RoHS Compliant By Exemption |
| 电压范围 | 200 mVDC to 1000 VDC, 200 mVAC to 750 VAC |
| 零件号别名 | 2727851 |
| 准确性 | 1 % |
| 最小/最大保持 | Yes |
| 数据保持 | No |
| DMM Type | :Hand Held |
| Voltage Measuring Range DC | :200mV to 1kV |
| Voltage Measuring Range AC | :200mV to 750V |
| Current Measuring Range DC | :200µA to 200mA |
| Current Measuring Range AC | :200µA to 200mA |
| Resistance Measuring Range | :200ohm to 20Mohm |
| Frequency Measuring Range | :- |
| Capacitance Measuring Range | :- |
| Temperature Measuring Range | :- |
| No. of Digits | :3.5 |
| DMM Response Type | :True RMS |
| DMM Functions | :AC/DC Current, AC/DC Voltage, Resistance |
| 插头类型 | :- |
| SVHC | :No SVHC (20-Jun-2013) |
| No. of Digits / Alpha | :3-1/2 |
| Weight (kg) | 0.3 |
| Tariff No. | 90303100 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
