HERGA
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 连接尺寸 | :0.125" |
| 联系配置 | :DPCO |
| Contact Current AC Max | :21A |
| Contact Voltage AC Max | :250V |
| 外部深度 | :43mm |
| External Diameter | :43mm |
| External Length / Height | :58mm |
| 外宽 | :40mm |
| MSL | :- |
| 材质 | :Nylon 12 body, neoprene diaphram, steel spring |
| No. of Fixing Holes | :4 |
| 工作压力范围 | :3psi to 5.5psi |
| Operating Temperature Max | :70°C |
| Operating Temperature Min | :-5°C |
| 系列 | :6742 |
| Weight (kg) | 0.078 |
| Tariff No. | 90329000 |
