TE Connectivity
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 线圈电流 | 36.3mA |
| 线圈电压 | 12VDC |
| 开启电压（最大值） | 8 VDC |
| 线圈类型 | Non Latching |
| 关闭电压（最小值） | 1.2 VDC |
| 线圈功率 | 436 mW |
| 触点形式 | SPDT (1 Form C) |
| 继电器类型 | General Purpose |
| 端接类型 | PC Pin |
| 切换电压 | 400VAC - Max |
| 释放时间 | 3ms |
| 封装 | Bulk |
| 工作温度 | -40°C ~ 70°C |
| 操作时间 | 7ms |
| 触点额定值（电流） | 8A |
| 标准包装 | 20 |
| 安装类型 | Through Hole |
| 触点材料 | Silver Cadmium Oxide (AgCdO) |
| 线圈电阻 | 330 Ohms |
| RoHS指令 | Lead free / RoHS Compliant |
| 操作功能 | Single Side Stable |
| Approx Dimensions (L x W x H) (mm [in]) | 28.00 x 10.40 x 25.10 [1.103 x .409 x .988] |
| 线圈抑制二极管 | Without |
| 安装 | PC Board |
| 符合RoHS / ELV符合记录 | Always was RoHS not ELV compliant |
| 电流 | 8 Amps |
| Coil Resistance (ohm) | 330 |
| 极化 | No |
| 驱动系统 | DC |
| Lead Free Solder Processes | Wave solder capable to 240C, Wave solder capable to 260C, Wave solder capable to 265C |
| FCC Part 68 Isolation | n/a |
| MainCategory | Relays |
| Wiring Diagram | 1 Form C |
| Coil Rating | n/a |
| SubCategory | General Purpose Relay |
| 符合RoHS / ELV标准 | RoHS/Not ELV Compliant |
| 联系配置 | 1C SPDT |
| Coil Magnetic System | Monostable |
| Coil Insulation Classification | n/a |
| 评论 | Vertical Version |
| 批准标准 | UL Recognized, CSA Certified, VDE Component Mark |
| Coil Power, Nominal | 450 mW |
| 端接类型 | Printed Circuit Terminals |
| LED指示灯 | Without |
| 外壳 | Washable |
| Dimensions L x W x H | 28.1 x 10.4 x 25.1 mm |
| Ucoil | 12 |
| Rcoil | 330 |
| Switching voltage | 250 |
| 联系方式 | 1 change-over (CO) |
| Pcoil | 500 |
| Switching current | 8 Amax. |
| Relay type | Monostable |
| Switching capacity | 2000 VA |
| 测试电压 | 4 |
| 间距 | 2.54 |
| Temperature range | -40...+70 °C |
| Protection rating | IP 67 |
| Contact material | AgCdO |
| 线圈功率额定值（直流） (mW) | 440 |
| 绝缘漏电类 (mm) | 3 – 5.5 |
| 环境保护类别 | RTIII |
| 绝缘间隙类 (mm) | 2.5 – 4 |
| 端子材料 | AgCdO |
| 端子类型 | PCB-THT |
| 端子开关电压（最大值） (VAC) | 400 |
| 端子电压额定值 (VAC) | 250 |
| 线圈电压额定值 (VDC) | 12 |
| 端子极数 | 1 |
| 继电器安装类型 | 印刷电路板 |
| 端子排列方式 | 1 Form C (CO) |
| 功率继电器类型 | 标准 |
| Contact Current Rating (Max) (A) | 8 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
