TE CONNECTIVITY
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 连接器类型 | :Circular Industrial |
| 系列 | :TRIAD |
| Connector Body Material | :Copper Zinc Alloy |
| 性别 | :Receptacle |
| Connector Mounting | :Cable |
| Connector Shell Size | :- |
| 插入安排 | :- |
| No. of Contacts | :7 |
| 接触端子 | :Solder |
| 触点材料 | :- |
| 触点电镀 | :Gold |
| Cable Diameter Max | :5mm |
| 接触电阻 | :5mohm |
| 额定电流 | :1A |
| 可燃性等级 | :UL94V-0 |
| 房屋类型 | :Copper,zinc,tribor plating 4µm |
| IP / NEMA Rating | :IP65 |
| No. of Mating Cycles | :500 |
| Operating Temperature Max | :85°C |
| Operating Temperature Min | :-40°C |
| 面板厚度 | :4mm |
| Test Voltage | :500V |
| Voltage Rating V AC | :60V |
| Wire Area Size Max | :0.25mm² |
| 工作电压 | :60V |
| Weight (kg) | 0.0016 |
| Tariff No. | 85369010 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
