TE Connectivity
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| RoHS | RoHS Compliant |
| 电阻 | 33 MOhms |
| 容差 | 1 % |
| 额定功率 | 400 mW |
| 温度系数 | 100 PPM / C |
| 系列 | HB |
| 端接类型 | Radial |
| 额定电压 | 1 kV |
| 工作温度范围 | - 55 C to + 125 C |
| 外形尺寸 | 2.6 mm W x 8 mm L x 12.5 mm H |
| 表壳厚度 | 12.5 mm |
| 表壳长度 | 8 mm |
| 表壳宽度 | 2.6 mm |
| 引线直径 | 0.6 mm |
| 引线间距 | 5 mm |
| 产品 | Thick Film Resistors Leaded |
| 类型 | High Value, High Voltage Resistors |
| 零件号别名 | 1625960-8 |
| 机箱样式 | Moulded |
| 深度 | 2.6mm |
| 身高 | 12.5mm |
| 长度 | 8mm |
| 最高工作温度 | +125°C |
| 最大温度系数 | +100ppm/°C |
| 最低工作温度 | -55°C |
| 最低温度系数 | -100ppm/°C |
| 技术 | Thick Film |
| RoHS指令 | Compliant |
| 产品范围 | :TE CONNECTIVITY - HB Series |
| 电阻公差 | :± 1% |
| Resistor Case Style | :Radial Leaded |
| Resistor Element Material | :Thick Film |
| 外部深度 | :2.6mm |
| External Length / Height | :12.5mm |
| 外宽 | :8.0mm |
| Operating Temperature Max | :125°C |
| Operating Temperature Min | :-55°C |
| Resistor Mounting | :Through Hole |
| Weight (kg) | 0.001 |
| Tariff No. | 85331000 |
| Brand/Series | HBSeries |
| Material,Element | ThickFilm |
| PackageType | EpoxyCoat |
| Power,Rating | 0.4W |
| 端子 | Radial |
| TycoPartNumber | 1625960-8 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
