TE Connectivity / Raychem
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 产品种类 | Heat Shrink Tubing and Sleeves |
| RoHS | RoHS Compliant |
| 类型 | Boot, 90 Degree |
| 材质 | Polyolefin (PO) |
| 颜色 | Black |
| 最低收缩温度 | + 125 C |
| 恢复直径 | 22.4 mm, 8.4 mm |
| 内径 | 36 mm, 36 mm |
| 耐化学性 | Yes |
| 产品特点 | Without adhesive, 90 deg angle |
| 可燃性等级 | UL 224 |
| 最高温度 | + 135 C |
| 工作温度范围 | - 55 C to + 135 C |
| 零件号别名 | 812846-000 812846N010 |
| 胶粘剂描述 | Adhesive Purchased Separately. |
| Angle | 90° |
| 粘合代码 | S1125 |
| 应用 | General Purpose |
| Operating Temperature (°C) | -55 â +135 |
| RoHSELV合规性 | RoHS compliant, ELV compliant |
| Lead Free Solder Processes | Not relevant for lead free process |
| 品牌 | Raychem |
| Entry Size - Solid or Fixed Adapter | 8 |
| 产品类型 | Molded Boot |
| Entry Size - Spin Coupling Adapter | 12 |
| 姓 | 222K1 |
| 入口尺寸编织或磁力成型适配器 | 12, 13, 14, 15 |
| 物料编码 | 3 |
| 评论 | Contact Raychem for additional adhesive and/or cut off boot length information |
| 批准标准 | DEF Std 59-97 Issue 3 Type DA, MIL-I-81765/1 Class I, UL224 E85831 |
| 材料系统编码 | 10 |
| Cable Diameter Range (mm (in)) | 8.40 â 19.00 [0.331 â 0.748] |
| 胶粘剂预涂层 | Without |
| 入口尺寸Tinel锁适配器 | 10, 12, 14 |
| RoHSELV符合记录 | Always was RoHS compliant |
| 尺寸 | 52 |
| 粘性内衬 | No |
| 内径主 | 36mm |
| 内径中学 | 36mm |
| 最高工作温度 | +135°C |
| 最低工作温度 | -55°C |
| 分组讨论数 | 1 |
| 收缩直径主 | 22.4mm |
| 缩水直径中学 | 8.4mm |
| RoHS指令 | Compliant |
| 材料 | 半刚性聚烯烃 |
| Power Cable Accessory | No |
| 入口尺寸（编织或磁力成型适配器） | 12, 13, 14, 15 |
| Molded Part Type | Molded Boot |
| Wire/Cable Outside Diameter | .39 in, .43 in, .433 in, .47 in, .55 in, .63 in, 10 mm, 11 mm, 12 mm, 14 mm, 16 mm |
| 入口尺寸（实心或固定适配器） | 8 |
| Lipped | Yes |
| Adhesive Pre-Coat | No |
| 电缆直径范围 | 8.4 – 19 mm [ .331 – .748 in ] |
| Adhesive Options | S1006 Separate Adhesive, -55°C – 135°C (-67°F – 275°F), S1017 Separate Adhesive, -20°C – 60°C (-4°F – 140°F), S1030 Separate Adhesive, -80°C – 80°C (-112°F – 176°F), S1048 Separate Adhesive, -55°C – 105°C (-67°F – 221°F), S1125 Separate Adhesive, -75°C – 150°C (-103°F – 302°F) |
| 符合政府资质 | 否 |
| 粘合剂类型 | 单独购买的粘合剂 |
| 入口尺寸（Tinel-Lock 适配器） | 10, 12, 14 |
| 工作温度范围 (°C) | -55 – 135 |
| 材料系统代码 | 10 |
| 入口尺寸（自旋耦合适配器） | 12 |
| Fluid/Chemical Resistance | Suitable for occasional exposure to fluids |
