Souriau
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 连接器类型 | :Circular Industrial |
| 系列 | :UTG |
| Connector Body Material | :Glass Filled Thermoplastic |
| 性别 | :Plug |
| 联系人性别 | :Pin |
| Connector Mounting | :Cable |
| Connector Shell Size | :10 |
| 插入安排 | :10-3 |
| No. of Positions | :3 |
| 主体镀层 | :Nickel |
| 可燃性等级 | :UL94V-0 |
| IP / NEMA Rating | :IP65 |
| 绝缘电阻 | :5000Mohm |
| No. of Mating Cycles | :500 |
| Operating Temperature Max | :125°C |
| Operating Temperature Min | :-55°C |
| Weight (kg) | 0.02576 |
| Tariff No. | 85369010 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
