Qualtek
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 静态压力 | 0.110 in H2O (27.4 Pa) |
| 材料 - 刀片 | Plastic |
| 噪音 | 26.2 dB(A) |
| 额定电流 | 0.030A |
| 电压 - 额定 | 230VAC |
| 标准包装 | 60 |
| 材料 - 框架 | Aluminum |
| 轴承类型 | Ball |
| 尺寸/尺寸 | Square - 80mm L x 80mm H x 38mm W |
| 重量 | 0.706 lb (320.24g) |
| 工作温度 | 14 ~ 158°F (-10 ~ 70°C) |
| Air Flow | 24.0 CFM (0.680m³/min) |
| 风扇类型 | Tubeaxial |
| 端子 | 2 Terminals |
| 功率（瓦特） | 5.0W |
| 转速 | 2400 RPM |
| 框架尺寸（mm ） | 80 mm x 38 mm x 80 mm |
| 产品 | Fans |
| 产品种类 | Fans |
| 类型 | Axial Fans |
| 端接类型 | Terminals |
| 外壳材料 | Aluminum Alloy |
| 电流类型 | AC |
| 电源电压 | 230 V |
| 风量 | 22 CFM, 24 CFM |
| 额定功率 | 6 W, 5 W |
| 速度 | 2300 RPM, 2400 RPM |
| RoHS | RoHS Compliant |
| AirFlow | 22/24CFM |
| BearingType | Ball |
| Brand/Series | FAA1-08038Series |
| 配置 | Square |
| Current,Rating | 0.04/0.03A |
| 外形尺寸 | 3.2x3.2x1(80x80x25)In.(mm) |
| Dimensions,Inches | 3.2x3.2x1In. |
| Dimensions,mm | 80x80x25mm |
| 方向 | ExhaustoverStruts |
| FanType | AC |
| 频率 | 50/60Hz |
| 材质 | AluminumAlloy |
| NoiseLevel | 25.3/26.2dBA |
| Power,Rating | 6/5W |
| PrimaryType | Fans |
| 回转 | CW |
| 尺寸 | 3.2x1(80x25)In.(mm) |
| Size,Fan | 3.2x1(80x25)In.(mm) |
| StaticPressure | 0.107/0.11In.(H2O) |
| TemperatureRange | -10to70°C |
| Temperature,Operating,Maximum | 70°C |
| Temperature,Operating,Minimum | -10°C |
| Voltage,Rating | 230VAC |
| RoHS指令 | RoHS Compliant Part |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
