PANASONIC
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 产品范围 | :PANASONIC - ELL-6SH Series |
| 电感 | :82µH |
| Inductance Tolerance | :± 20% |
| Inductor Construction | :Shielded |
| DC Resistance Max | :0.6ohm |
| RMS Current (Irms) | :450mA |
| Case Dimensions | :6.4mm x 6mm x 3.3mm |
| 外部深度 | :6mm |
| External Length / Height | :3mm |
| 外宽 | :6mm |
| 电感类型 | :Choke |
| No. of Pins | :2 |
| 封装 | :Cut Tape |
| 系列 | :6SH |
| Weight (kg) | 0.00034 |
| Tariff No. | 85045095 |
| Current,Rating | 0.45A |
| Frequency,Test | 100kHz |
| Resistance,DC | 600mΩ |
| 端子 | SMT |
| 容差 | ±20% |
| 类型 | Chokes |
| RoHS指令 | RoHS Compliant Part |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
