Panasonic
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 芯材 | Ferrite |
| 深度 | 8.5mm |
| 外形尺寸 | 10 x 8.5 x 13mm |
| 身高 | 13mm |
| 电感 | 680 μH |
| 引线间距 | 5mm |
| 长度 | 10mm |
| 最大直流电流 | 320mA |
| 最大直流电阻 | 930mΩ |
| 容差 | ±10% |
| 产品范围 | :PANASONIC - ELC-08D Series |
| Inductance Tolerance | :± 10% |
| DC Resistance Max | :0.93ohm |
| RMS Current (Irms) | :320mA |
| Case Dimensions | :8mm x 13mm |
| DC Current Rating | :320mA |
| Inductor Case Style | :Radial Leaded |
| 引线间距 | :5mm |
| No. of Pins | :2 |
| Weight (kg) | 0.0025 |
| Tariff No. | 85045095 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
