PANASONIC
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 产品范围 | :PANASONIC - HC Series |
| 电容 | :270µF |
| 电容公差 | :± 20% |
| 额定电压 | :400V |
| 直径 | :25mm |
| 血沉 | :0.675ohm |
| 身高 | :40mm |
| 引线间距 | :10mm |
| Life Time @ Temperature | :2000 hours @ 105°C |
| Operating Temperature Min | :-25°C |
| Operating Temperature Max | :105°C |
| AC Ripple Current @ 120Hz | :1.22A |
| Capacitor Terminals | :Quick Connect, Snap-In |
| ESR Frequency | :120Hz |
| External Length / Height | :40mm |
| No. of Pins | :2 |
| Operating Lifetime | :2000h |
| 工作温度范围 | :-25°C to +105°C |
| PCB孔直径 | :2mm |
| Ripple Current AC | :1.22A |
| Ripple Current Frequency | :120Hz |
| Ripple Current Temperature | :105°C |
| 系列 | :TSHC |
| Tolerance + | :20% |
| Tolerance - | :20% |
| Voltage Rating V DC | :400V |
| Weight (kg) | 0.03141 |
| Tariff No. | 85322900 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
