PANASONIC
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 单位包 | 500 |
| 最小起订量 | 9000 |
| 产品范围 | :PANASONIC - FP Series |
| 电容 | :1800µF |
| 电容公差 | :± 20% |
| 额定电压 | :6.3V |
| Capacitor Case Style | :Radial Can - SMD |
| 直径 | :10mm |
| 血沉 | :0.08ohm |
| 身高 | :10.2mm |
| Ripple Current AC | :850mA |
| 封装 | :Cut Tape |
| Life Time @ Temperature | :2000 hours @ 105°C |
| Operating Temperature Min | :-55°C |
| Operating Temperature Max | :105°C |
| External Length / Height | :10.2mm |
| 泄漏电流 | :113.4µA |
| 工作温度范围 | :-55°C to +105°C |
| 系列 | :FP |
| Weight (kg) | 0.01 |
| Tariff No. | 85322200 |
| Material,Element | AluminumElectrolytic |
| Temperature,Operating,Maximum | 105°C |
| Temperature,Operating,Minimum | –55°C |
| 端子 | SMT |
| 容差 | ±20% |
| Voltage,Rating | 6.3VDC |
| RoHS指令 | RoHS Compliant Part |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
