| Type | Description |
|---|---|
| Power Supply Output Type | :Fixed |
| Input Voltage VAC | :90V to 264V |
| No. of Outputs | :3 |
| Output Voltage Nom. | :5V, 24V, 12V |
| Output Current Max | :6A, 2A, 800mA |
| Output Power Max | :63W |
| SVHC | :No SVHC (20-Jun-2013) |
| 应用范围 | :General Purpose |
| 外部深度 | :127mm |
| External Length / Height | :33.5mm |
| 外宽 | :76.2mm |
| 身高 | :30.5mm |
| 输入频率 | :63Hz |
| 长度 | :127mm |
| 安装类型 | :Chassis |
| 输出电流 | :6A |
| Output Current - Output 2 | :2A |
| Output Current Nom - Output 3 | :800mA |
| 输出功率 | :63W |
| 输出电压 | :5V |
| Output Voltage - Output 2 | :24V |
| Output Voltage Nom - Output 3 | :12V |
| 额定功率 | :63W |
| 电源类型 | :Switch Mode |
| Supply Frequency Max | :63Hz |
| Supply Frequency Min | :47Hz |
| 电源电压 | :264V |
| Supply Voltage Max | :264V |
| Supply Voltage Min | :90V |
| Supply Voltage Typ | :110V AC, 230V AC |
| 重量 | :250g |
| 宽度 | :76.2mm |
| Weight (kg) | 0.25 |
| Tariff No. | 85044090 |
| 输出数 | 3 |
| 类型 | Enclosed |
| 产品特点 | Adjustable Output, DC Input Capable, Universal Input |
| 标准包装 | 5 |
| 电压 - 输出1 | 5V |
| 电压 - 输出2 | 24V |
| 电压 - 输出3 | 12V |
| 尺寸/尺寸 | 5.00" L x 3.00" W x 1.20" H (127.0mm x 76.2mm x 30.5mm) |
| 效率 | 80% |
| 功率（瓦特） | 60W |
| 电流 - 输出（最大） | 6A, 2A, 800mA |
| Minimum Load Required | Yes |
| 功率（瓦特） - 最大 | 63W |
| 电压 - 电压 | 90 ~ 264 VAC |
| 工作温度 | 0°C ~ 70°C |
| 电压 - 隔离 | 3kV (3000V) |
| RoHS指令 | Lead free / RoHS Compliant |
