XP POWER
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| Power Supply Output Type | :Adjustable, Fixed |
| Input Voltage VAC | :90V to 264V |
| No. of Outputs | :3 |
| Output Voltage Nom. | :5V, 12V, -12V |
| Output Current Max | :15A, 6A, 800mA |
| Output Power Max | :120W |
| SVHC | :No SVHC (20-Jun-2013) |
| 应用范围 | :General Purpose |
| Approval Bodies | :CE, CSA, cUL, EN, UL |
| 效率 | :80% |
| 外部深度 | :39.2mm |
| External Length / Height | :127mm |
| 外宽 | :81.35mm |
| 身高 | :127mm |
| 输入频率 | :63Hz |
| 输入电压 | :90V AC to 260V AC , 120V DC to 370V DC |
| 长度 | :39.2mm |
| 线路调整 | :1% |
| 负载调整率 | :5% |
| 安装类型 | :Chassis |
| Operating Temperature Max | :70°C |
| Operating Temperature Min | :0°C |
| 输出电流 | :15A |
| Output Current - Output 2 | :6A |
| Output Current Nom - Output 3 | :800mA |
| Output Ripple and Noise Voltage pk-pk | :1% |
| 输出电压 | :5V |
| Output Voltage - Output 2 | :12V |
| Output Voltage Nom - Output 3 | :-12V |
| 额定功率 | :120W |
| 电源类型 | :Switch Mode |
| Supply Frequency Max | :63Hz |
| Supply Frequency Min | :47Hz |
| 电源电压 | :264V |
| Supply Voltage Max | :264V |
| Weight (kg) | 0.52 |
| Tariff No. | 85044090 |
