Omron Electronics
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 额定电流 | 5A (AC), 4A (DC) |
| 操作力，扭矩 | 150gf |
| 额定电压 - AC | 125V |
| 电气寿命 | 200,000 Cycles |
| 端接类型 | Solder Lug |
| 工作温度 | -25°C ~ 85°C |
| 机械寿命 | 30,000,000 Cycles |
| Differential Travel | 0.004" (0.1mm) |
| 超程 | 0.020" (0.5mm) |
| 标准包装 | 500 |
| 预行程 | 0.020" (0.5mm) |
| 开关功能 | On-Mom |
| 工作职位 | 0.330" (8.4mm) |
| 电路 | SPST-NC |
| 额定电压 - DC | 30V |
| 防护等级 | IP40 |
| 安装类型 | Chassis Mount |
| 封装 | Bulk |
| 执行器类型 | Round (Pin Plunger) |
| 释放力 | 25gf |
| 其他名称 | SS52 |
| CAD绘图 | 3D CAD Model |
| 联系配置 | SPST-NC |
| 触点额定电流 | 5 A @ 125 V ac, 5 A @ 14 V dc |
| 触点材料 | Silver |
| IP等级 | IP40 |
| 最高工作温度 | +85°C |
| 最低工作温度 | -25°C |
| 操作力 | 1.47 N |
| 终端类型 | Solder |
| RoHS指令 | Compliant |
| 工厂包装数量 | 500 |
| 电压额定值AC | 125 V |
| 产品种类 | Basic / Snap Action Switches |
| 安装 | Panel |
| 触点形式 | SPST |
| 系列 | SS |
| 执行器 | Plunger, Pin |
| 零件号别名 | 382577 |
| 类型 | Miniature |
| RoHS | RoHS Compliant |
| AC contacts rating (at resistance load) | 5 A / 125 VAC |
| Leads | for soldering |
| Contacts configuration | SPST-NC |
| Switches features | without lever |
| Switching torque | 1.47N |
| Mechanical durability | 30000000cycles |
| Multiplicity | 1 |
| Electrical life | 200000cycles |
| Gross weight | 1 g |
| Stable positions number | 1-position |
| Operating temperature | -25...85°C |
| Min insulation resistance | 100MΩ |
| Body dimensions | 19.8 x 6.4 x 10.2mm |
| Terminal pitch | 7.3mm |
| 密封 | IP40 |
| Switching method | ON-(OFF) |
| Max contact resistance: | 30mΩ |
| Switch type | microswitch |
| SubCategory | Snap-Action Switch |
| MainCategory | Switches |
| 联系方式 | 1 break contact (NC) |
| 额定电流 | 5 A |
| Actuation | Plunger |
| Actuation force | 1.47 N |
| Termination type | Soldering Connection |
| 额定电压 | 125 |
| Temperature range | -25...+85 °C |
| Protection rating | IP 40 |
| Contact material | Ag |
