Omron Industrial
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| Tensione d'alimentazione d'esercizio minima | 10 |
| TIPO二terminale | Pre-Wire |
| Tensione d'esercizio tipica | 12|15|18|24 |
| Distanza sensore | 0.8 |
| Package Height | 10.7 |
| Modalità commutazione | NO |
| Materiale德尔CORPO | ABS |
| Montaggio | Panel |
| Isteresi | 10% |
| Temperatura d'esercizio minima | -25 |
| 阶梯德尔CORPO | Barrel |
| Massima temperatura d'esercizio | 70 |
| Tensione d'alimentazione d'esercizio massima | 30 |
| Package Width | 8 |
| Tensione di alimentazione DC | 10 to 30 |
| PCB | 2 |
| Package Length | 459 |
| 符合UE | Compliant |
| Frequenza di risposta | 1500 |
| Classificazione模/ IC | Module |
| NUMERO DEI针 | 2 |
| 工业别名 | E2EC-CR8D1 |
| 子类别 | Proximity Sensor |
| 交货期 | 56 Days |
| 屏蔽 | Shielded |
| 传感器类型 | Inductive |
| 检测对象 | Metallic |
| 响应频率 | 1.5kHz |
| 输出类型 | NPN-NO |
| 材料 - 主体 | Brass |
| 感应距离为5mm | 0.031" (0.8mm) |
| 标准包装 | 1 |
| 电压 - 电源 | 10 V ~ 30 V |
| 终端类型 | 2-Wire |
| 封装/外壳 | Cylinder with Amplifier |
| RoHS指令 | Lead free / RoHS Compliant |
| 工厂包装数量 | 1 |
| 产品种类 | Proximity Sensors |
| 检测方法 | Inductive |
| 系列 | E2EC |
| 桶规格 | 3 mm diameter |
| 安装风格 | Panel |
| 电源电压 | 24 V |
| 最低工作温度 | - 25 C |
| 输出配置 | NO |
| 零件号别名 | 1272985 |
| 最高工作温度 | + 70 C |
| RoHS | RoHS Compliant |
| Sensor Input | :Inductive |
| Sensing Range Max | :0.8mm |
| Supply Voltage DC Min | :10V |
| Supply Voltage DC Max | :30V |
| Load Current RMS Max | :100mA |
| Sensing Face Diameter | :3mm |
| Sensor Output | :SPST-NO |
| Weight (kg) | 0.059 |
| Tariff No. | 90318038 |
| Sensor type | inductive |
| Multiplicity | 1 |
| 连接方式 | lead 2m |
| Switching frequency max | 1500Hz |
| Gross weight | 0.03 kg |
| Front type | embedded |
| Body material | brass |
| Operating temperature | -25...70°C |
| 电源电压 | 12...24V DC |
| Range | 0...0.8mm |
| Output configuration | 2-wire NO |
| 密封 | IP67 |
| Switch housing | Ø3 |
| Operating current max | 100mA |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
