Omron Electronics
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 额定电流 | 100mA (AC/DC) |
| 操作力，扭矩 | 200gf |
| 额定电压 - AC | 125V |
| 电气寿命 | 1,000,000 Cycles |
| 端接类型 | Wire Leads |
| 工作温度 | -40°C ~ 85°C |
| 机械寿命 | 10,000,000 Cycles |
| Differential Travel | 0.016" (0.4mm) |
| 超程 | 0.040" (1.0mm) |
| 标准包装 | 10 |
| 预行程 | 0.047" (1.2mm) |
| 开关功能 | On-Mom |
| 工作职位 | 0.579" (14.7mm) |
| 电路 | SPDT |
| 额定电压 - DC | 30V |
| 防护等级 | IP67 - Dust Tight, Waterproof |
| 安装类型 | Chassis Mount |
| 封装 | Bulk |
| 执行器类型 | Round (Pin Plunger) |
| 释放力 | 30gf |
| 其他名称 | D2VW011M |
| CAD绘图 | 3D CAD Model |
| 联系配置 | SPDT-NO/NC |
| 触点额定电流 | 0.1 A @ 125 V ac, 0.1 A @ 30 V dc |
| 触点材料 | Gold Alloy |
| IP等级 | IP67 |
| 最高工作温度 | +85°C |
| 最低工作温度 | -40°C |
| 操作力 | 1.96 N |
| 终端类型 | Pre-wired |
| RoHS指令 | Compliant |
| 工厂包装数量 | 10 |
| 电压额定值AC | 125 V |
| 产品种类 | Basic / Snap Action Switches |
| 安装 | Panel |
| 触点形式 | SPDT |
| 直流电额定电压 | 30 V |
| 系列 | D2VW |
| 执行器 | Lever |
| 零件号别名 | 418467 D2VW011MNC |
| 类型 | Standard |
| RoHS | RoHS Compliant |
| AC contacts rating (at resistance load) | 0.1 A / 125 VAC |
| Leads | 300mm leads, on right |
| Contacts configuration | SPDT |
| Switches features | without lever |
| Switching torque | 1.96N |
| Mechanical durability | 10000000cycles |
| Multiplicity | 1 |
| Electrical life | 1000000cycles |
| Collective package [pcs] | 10 |
| Gross weight | 1 g |
| Operating temperature | -40...85°C |
| Switch type | microswitch |
| 接触镀层 | gold plated |
| Stable positions number | 1-position |
| Body dimensions | 33 x 10.3 x 15.9mm |
| 密封 | IP67 |
| spg | 10 |
| DC contacts rating (at resistance load) | 0.1 A / 30 VDC |
| Max contact resistance: | 100mΩ |
| Switching method | ON-(ON) |
| SubCategory | Snap-Action Switch |
| MainCategory | Switches |
| 联系方式 | 1 change-over (CO) |
| 额定电流 | 0.1 A |
| Actuation | Plunger |
| Actuation force | 1.96 N |
| Termination type | Stranded Wires, 300 mm |
| 额定电压 | 125 |
| Temperature range | -40...+85 °C |
| Protection rating | IP 67 |
| Contact material | Au |
| 最低工作温度 | -40°C |
| IP 防护等级 | IP67 |
| 最高工作温度 | +85°C |
| 操作力 | 1.96 N |
| 执行器类型 | 引脚柱塞 |
| 触点配置 | 单刀双掷 - 常开/常闭 |
| 工作温度范围 | -40 → +85°C |
| CAD 绘图 | 3D CAD 模型 |
| 触点材料 | 金合金 |
| 机械寿命 | 10000000Operations |
| 释放力 | 0.29N |
| 触点额定电流 | 100 mA @ 30 V 直流 |
| 接端类型 | Pre-wired |
