Hirschmann Test & Measurement
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 颜色 | Blue |
| 连接器A性别 | Male |
| 连接器的取向 | Straight |
| 连接器B性别 | Female |
| 连接器B方向 | Straight |
| 接头尺寸 | 4 mm |
| 触点材料 | Beryllium Copper |
| 额定电流 | 16A |
| 绝缘材料 | PVC |
| 引线长度 | 100cm |
| 最高工作温度 | +70°C |
| 最低工作温度 | -15°C |
| 额定电压 | 60V dc |
| Insulator Colour | :Blue |
| Test Connector Type A | :4mm Banana Plug Shrouded |
| Test Connector Type B | :4mm Banana Plug Shrouded |
| SVHC | :No SVHC (20-Jun-2013) |
| 大会电缆类型 | :Test |
| 电缆长度 | :1m |
| 连接A型 | :4mm Banana Plug, Shrouded |
| 接触电阻 | :22mohm |
| Operating Temperature Max | :70°C |
| Operating Temperature Min | :-15°C |
| Voltage Rating V DC | :60V |
| Weight (kg) | 0.048 |
| Tariff No. | 85369010 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
