Hengstler
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 连接类型 | Screw |
| 计数方向 | Up |
| 计数模式 | Impulses |
| 数字高度 | 4 mm |
| 输入类型 | Voltage |
| 最大计数频率 | 10Hz |
| 最高工作温度 | +50°C |
| 最低工作温度 | -10°C |
| 安装类型 | Panel |
| 数字位数 | 6 |
| 复位方法 | No Reset |
| 电源电压 | 5 V dc |
| 重量 | 20g |
| No. of Digits / Alpha | :6 |
| Supply Voltage Range | :- |
| 功耗 | :80mW |
| Panel Cutout Height | :14.4mm |
| Panel Cutout Width | :27mm |
| Counting Speed | :10Hz |
| Operating Temperature Min | :-10°C |
| Operating Temperature Max | :50°C |
| Count Speed Max | :10Hz |
| 外部深度 | :34mm |
| External Length / Height | :20mm |
| 外宽 | :30mm |
| 工作温度范围 | :-10°C to +50°C |
| Operating Voltage Tolerance + | :10% |
| Panel Cut-out Size | :14.2x27mm |
| Supply Voltage V DC | :5VDC |
| Weight (kg) | 0.014 |
| Tariff No. | 90291000 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
