FLIR Systems
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 描述/功能 | Pinless moisture meter with field replacable sensors |
| 产品特点 | LCD Display, Bluetooth, FLIR METERLiNK compatable |
| 措施 | Humidity, Temperature |
| 设备类型 | Meter |
| 测量元件 | Moisture |
| 电压 | 9 V |
| 准确性 | 2.5 % |
| RoHS | RoHS Compliant By Exemption |
| 配置 | Handheld |
| PrimaryType | MoistureMeter |
| Meter type | thermo-hygrometer |
| 显示 | LCD |
| 外形尺寸 | 139 x 72 x 42mm |
| 重量 | 290g |
| Optical resolution | 8:1 |
| Multiplicity | 1 |
| 电源 | 1 battery 9V |
| Humidity measuring accuracy | ±3% |
| Sampling | 2x/s |
| Gross weight | 0.68 kg |
| Temperature measuring range | -28...77°C |
| Temperature measurement accuracy | ±2% |
| Non-contact temperature measuring range | -20...200°C |
| Humidity measuring range | 0...99% RH |
| Non-contact temperature measuring accuracy | ±3.5% or ±5°C |
| 最佳准确度 | Humidity:±2.5 %RH|Sensor:±3.6 °F|IR Temperature:±3.5 %|Vapor Pressure:±2 % |
| 显示器类型 | LCD |
| 最小测量 | Pinless:0 %|Pin:0 %|Humidity:0 %RH|Sensor:-18 °F|IR Temperature:-4 °F|Vapor Pressure:0 kPa |
| 电源 | Battery |
| Brand Name | FLIR |
| 最大尺寸 | Pinless:99.9 %|Pin:99 %|Humidity:99 %RH|Sensor:+170 °F|IR Temperature:+392 °F|Vapor Pressure:20 kPa |
| 电池类型 | 9V Alkaline Battery |
| 产品类型 | Moisture Meter |
| Dimensions L x W x H | 139 x 72 x 42 mm |
| Min Temperature | -28 |
| Measuring error, temperature, IR | ±3.5% |
| Electrical supply | 1 x 6LR61/9V |
| %rh resolution | 2.5 |
| Interfaces | Bluetooth |
| No of inputs | 3 |
| Delivery with | Battery |
| Sensor type/thermocouples | IR |
| Humidity measurement range max | 99 |
| Wood moisture | 0 %...99.9 % |
| Temperature range, IR | -20...+200 °C |
| 系列 | Flir MR77 |
| Measuring error °C | ±2 |
| Humidity measurement range min | 0 |
| Max temperature | +77 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
