Hammond Manufacturing
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 评分 | IP54 |
| 面积（长x宽） | 14.0" (90cm) |
| 产品特点 | Card Guides |
| 颜色 | Translucent - Clear |
| 标准包装 | 1 |
| 材质 | Plastic, Polycarbonate |
| 身高 | 1.732" (43.99mm) |
| 尺寸/尺寸 | 4.335" L x 3.236" W (110.11mm x 82.19mm) |
| 集装箱类型 | Box |
| 设计 | Cover Included |
| 材料阻燃等级 | UL91 V-0 |
| 厚度 | 0.079" (2.01mm) |
| 装运信息 | Shipped from Digi-Key |
| RoHS指令 | Compliant |
| 外宽 | 3.2 in |
| 外部高度 | 1.6 in |
| 产品 | Electronics Enclosures |
| 产品种类 | Enclosures, Boxes, & Cases |
| IP等级 | IP 54 |
| 可燃性等级 | UL 94 V-0 |
| 类型 | Windowed |
| RoHS | RoHS Compliant |
| 外部深度 | 4.3 in |
| Weight (kg) | 0.103 |
| Tariff No. | 39231000 |
| Brand/Series | 1591"T"Series |
| 配置 | Desktop |
| 外形尺寸 | 4.300x3.200x1.760In. |
| IPRating | IP54 |
| Dimension Z | 40mm |
| Dimension Y | 110mm |
| Dimension X | 82mm |
| Multiplicity | 1 |
| Enclosure material | polycarbonate |
| Gross weight | 0.1 kg |
| Body colour | transparent |
| spg | 10 |
| 密封 | IP54 |
| Enclosure series | 1591 |
| Collective package [pcs] | 10 |
| 机箱类型 | multipurpose |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
