Hammond Manufacturing
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 评分 | IP65 |
| 面积（长x宽） | 22.3" (144cm) |
| 产品特点 | Watertight |
| 重量 | 1.1 lbs (499g) |
| 颜色 | Unpainted |
| 标准包装 | 1 |
| 材质 | Metal, Aluminum |
| 身高 | 3.701" (94.01mm) |
| 尺寸/尺寸 | 4.724" L x 4.724" W (119.99mm x 119.99mm) |
| 集装箱类型 | Box with Mounting Flange |
| 设计 | Cover Included |
| 厚度 | 0.080" (2.03mm) |
| 装运信息 | Shipped from Digi-Key |
| 外宽 | 4.7 in |
| 外部高度 | 2.17 in |
| 产品 | Electrical Boxes |
| 产品种类 | Enclosures, Boxes, & Cases |
| IP等级 | IP 65 |
| 类型 | Water Resistant, Flanged Cover Panel |
| RoHS | RoHS Compliant |
| 外部深度 | 4.7 in |
| 外壳类型 | :Instrument |
| 外壳材质 | :Aluminium |
| 主体颜色 | :Unfinished |
| External Height - Imperial | :4.72" |
| External Height - Metric | :120mm |
| External Width - Imperial | :4.72" |
| External Width - Metric | :120mm |
| External Depth - Imperial | :3.54" |
| External Depth - Metric | :90mm |
| NEMA号 | :4X |
| SVHC | :No SVHC (20-Jun-2013) |
| Weight (kg) | 0.489 |
| Tariff No. | 76169990 |
| Brand/Series | 1590WSeries |
| 配置 | PanelMount |
| 外形尺寸 | 4.724x4.724x3.701In. |
| IPRating | IP65 |
| RoHS指令 | RoHS Compliant Part |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
