Hammond Manufacturing
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 评分 | IP54 |
| 面积（长x宽） | 18.7" (121cm) |
| 产品特点 | EMI Shielded |
| 颜色 | Unpainted |
| 标准包装 | 1 |
| 材质 | Metal, Aluminum |
| 身高 | 1.540" (39.12mm) |
| 尺寸/尺寸 | 5.230" L x 5.230" W (132.84mm x 132.84mm) |
| 集装箱类型 | Box |
| 设计 | Cover Included |
| 厚度 | 0.090" (2.29mm) |
| 其他名称 | HM451 |
| 装运信息 | Shipped from Digi-Key |
| 阀体材质 | Die Cast Aluminium Alloy |
| 颜色 | Unpainted |
| 外部尺寸 | 132.78 x 132.78 x 39.2mm |
| 外部高度 | 39.2 mm |
| 外部长度 | 132.78 mm |
| 外宽 | 132.78 mm |
| IP等级 | IP54 |
| 击倒数 | 0 |
| 屏蔽 | Yes |
| RoHS指令 | Compliant |
| 外宽 | 132.8 mm |
| 外部高度 | 35.2 mm |
| 产品 | Electrical Boxes |
| 产品种类 | Enclosures, Boxes, & Cases |
| 类型 | Water Resistant |
| RoHS | RoHS Compliant |
| 外部深度 | 132.8 mm |
| 外壳类型 | :Instrument |
| 外壳材质 | :Aluminium |
| 主体颜色 | :Unfinished |
| External Height - Imperial | :1.54" |
| External Height - Metric | :39.2mm |
| External Width - Imperial | :5.23" |
| External Width - Metric | :132.8mm |
| External Depth - Imperial | :5.23" |
| External Depth - Metric | :132.8mm |
| NEMA号 | :12K |
| SVHC | :No SVHC (20-Jun-2013) |
| Weight (kg) | 0.27 |
| Tariff No. | 76169990 |
| Brand/Series | 1590Series |
| 配置 | Desktop |
| 外形尺寸 | 5.230x5.230x1.540In. |
| IPRating | IP54 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
